The Hot Spot® Collection

SX ™

Is there a better value spa pool in the Hot Spring range than the SX? One of the more compact spas in the cost-effective yet feature-packed Hot Spot collection, the SX boasts a level of quality and technology that belies its price. Sprinkle in contemporary design and a soaking experience that melts all your cares away, and you have one of the most compelling spa pool propositions on the market.


3 Adults


183 x 196 x 84 cm


870 litres



Make it your own


{{ this.active_cabinet.label }}

{{ cabinet_option.label }}

{{ this.active_shell.label }}

{{ shell_option.label }}

A triple threat

Each of the three bucket seats found within the SX delivers an entirely unique hydromassage experience. Deep and perfectly comfortable, they fall into a central footwell that boasts its own array of jets. Two soakers can lean back into integrated pillows, while whoever finds themself in the corner seat will enjoy the delights of the Moto-Massage, the world’s first moving spa pool jet, that works its way up and down your spine for unmatched relief.

You can even create a custom massage, thanks to the intuitive IQ2020® control panel found in the side of the unit. Choose your seat, adjust your pressure, sit back and relax.

Minimalism maximised

The SX is a spa pool that Pythagorus would be proud of. Working from a base of European minimalism, the interior looks simple at first, all crisp and geometric, but the closer you inspect it, the more clever it becomes. The placement of every edge, face and jet has been carefully thought through, to create a layout that is far more complex than it looks, while offering a super comfortable soak.

The compact footprint of the SX also means that it can find a home where most other Hot Spring models can’t. 183cm x 196cm at its base, your deck, patio, courtyard or even balcony are potential homes, with the look of the spa enhancing any outdoor space.

A spa with smarts

There’s also a lot going on beneath the beautiful surface of the SX, with a suite of systems ensuring the work and cost of spa pool ownership - so often a turn-off - are replaced by relaxation and savings.

The SilentFlo® 5000 works to continually circulate water around the SX, which reduces jet noise and ongoing wear and tear. The ultra-efficient No-Fault heater and FiberCor® insulation work together to keep your water warm, significantly lowering your power bills all the while. Water care is made easy too, thanks to the cartridge-based FROG® system.

Product Specs

Seating Capacity

3 adults


183 x 196 x 84 cm

Water Capacity

870 litres


295 kg dry
1,400 kg filled*

Lighting System

6 multi-colour LED points of light, dimmable.

Jet Count


Hot Tub Jets

1 Moto-Massage® jet
1 XL Rotary Hydromassage jet
16 Directional Precision™ jets

Control System

IQ 2020™ with LCD control panel
240v/10amp, 50Hz


230v / 10amp / 50Hz
Other configurations**


No-Fault™ 2000w/230v

Jet Pump 1

Wavemaster™ 9200; Two-speed,
2.5 HP Continuous Duty,
5.2 HP Breakdown Torque

Circulation Pump

SilentFlo 5000® for quiet continuous filtration (optional)

Ozone System

FreshWater® III Corona Discharge (optional)

Water Carte Options

EverFresh® system with CD ozone (optional)

FROG® In-Line Cartridge Ready*


Effective Filtration Area

2.75 m2, top loading

Vinal Cover Colours

Nutmeg or Stone

Vinal Cover Options

9 to 6 cm tapered, 24 kg/m3 density
foam core

Cover Lifters (Optional)

CoverCradle™, CoverCradle II
or UpRite™

* Includes water and 3 adults weighing 79 kg. each
**Depending on local electrical circumstances
